AudioConnections
XLRConnectors
TheDX0.5hastwofemaleXLRinputjacksthatacceptbalancedline‐levelsignals.Whenconnectingabalancedsignal,besureit’s
wiredperAES(AudioEngineeringSociety)standards:

XLR
 Pin1–Shield(Ground)
 Pin2–Hot(+)
 Pin3–Cold(–)

Youshouldusehigh‐quality,shieldedcabletoconnectthesignalsourcetotheinputsocketsontheDX0.5.
 Highqualitymi crophonecablesworkwell.
 Foilshieldedcablesarecommonlyused
foraudiowiringininstalledsystems.
 Thebettertheshield,thebettertheimmunityfromexternallyinducednoise(likeEMIandRFI).Routethecableaway
fromACpowercordsandoutlets.Thesearecommonsourcesforhuminanaudiosignal.

Additionally,therearesixmaleXLRoutput
jacksonthe DX0.5.ThesearealsowiredaccordingtotheAESstandardslistedabove.

