Martin Audio DX0.5 User Manual


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 18

…………
TurntheEdit2[8]orEdit3[9]Controltoscrollbetweenthesethreechoices.PresstheEnterButton[10]onceaunitofdelayhas
beendecided.TheprocessorwillreturntotheDelayUnitssplashscreen.OrpresstheESCbutton[11]toreturntotheSystem
Utilitymenuwithout
makinganychanges.
Rampsonchanges
Whenengaged,suddenvolumechangesmaybeavoidedwhenchangingparametervalues,particularlywhenusingaWindows‐
basedPCtocontroltheunit.Disengagethisfeatureforliveapplicationssinceinstantresponsetochangeisdesired.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenRamps : OnandRamps : Off[default].
Ifchanging,pressthe
EnterButton[10]onlyoncehere.TheprocessorwillreturntotheRampsonchangessplashscreen.OrpresstheESCbutton[11]
toreturntotheSystemUtilitymenuwithoutmakinganychanges.
SoftwareVersion
Nothingmaybeeditedonthispage.PresstheEnterButton[10]toviewwhatversionofsoftwareisinstalledinthisDX0.5.Press
theEnter[10]orESC[11]ButtontoreturntotheSoftwareVersionsplashscreen.
PresetUtilities
Thisiswheretosave,recallanddeletepresetsontheDX0.5.ThisisusefulwhenthePAsystemhasmultiplesetupsfordifferent
environmentsorseveralloudspeakersystemsutilizingvaryingsetups.
Note:Asmentionedearlier,theDX0.5willloadupthelaststateitwasinwhenitwaspowered
down.
Asmentionedearlier,thewaytogetherefromthemainmenuisbypressingtheUtilityButton[12].OnceinsidetheUtilityMenu,
scrolltheNav/Edit1Control[7]clockwisetoP resetUtilities.NowpresstheEnterButton[10]againtoreachthesub‐menusas
listedbelow:

RecallaPreset
 SaveaPreset
 DeleteaPreset

Lookingateachofthesesub‐menusindividually;‐
1. TheNav/Edit1Control[7]isusedtonavigatebetweenthethreePresetUtilities.
2. TheESCbutton[11]isusedtoreturntothePresetUtilitiesmenu.
3. TheEnter
Button[10]isusedtoenterandeditthechosenPresetUtility.
PresstheEnterButton[10]toenterRecallaPreset.
RecallaPreset
Ifapresethasbeensavedearlier,itmayberecalledhere.Ifnopresetsarestoredintheunit,theprocessorwillreturntothe
RecallaPresetsplashscreen.
Ifpresetsareavailable,turntheEdit2[8]orEdit3[9]Controltoselectwhich presettorecall.Pressthe
EnterButton[10]toselect
apresetandagaintoconfirmrecall.ThepresetwillloadandtheprocessorwillreturntotheRecallaPresetsplashscreen.
SaveaPreset
Onceyourdesiredsystemsettingshavebeenprogrammedin,saveittotheDX0.5forrecalllater.TurntheEdit2[8]orEdit3[9]
Controltoscrollbetweenpresets1–24.PresstheEnterButton[10]onceyoudecidethelocationinwhichyouwishtosavethe
preset.
Next
youareabletonamethepreset.TheNav/Edit1Control[7]movesthecursorleftandrightwhiletheEdit2[8]andEdit3[9]
Controlschangethetext.Oncesatisfiedwiththeresults,presstheEnterButton[10]twice:oncetoselectandagaintoconfirm.
Theprocessorwillreturn
totheSaveaPresetsplashscreen.
Itispossibletosaveoveranexistingpreset.Ifattempted,youwillneedtoconfirmbypressingtheEnterButton[10]again.Or
presstheESCButton[11]toreturntothePresetUtilitiesmenuwithoutoverwritingthepreset.
