DX0.5 USERGUIDE
HAM09224UserGuideV1.0 8

…………
7. SelectthesystemsetupthatbestmatchesyourLoudspeakerSystem[moredetailsmaybe foundonpage17]:

 2xStereo+Sub[default].Twofull‐rangeloudspeakerpairsandapairof[monoby default]subwoofers
 2x2Way+SubTwobi‐ampfull‐rangeloudspeakersandapairof[monobydefault]
subwoofers
 2x3WayTwotri‐ampfull‐rangeloudspeakersorstereosubswithtwobi‐ampspeakers
 3xStereoThreefull‐rangeloudspeakerpairs
 1x6WayMonocontrolofsixfullrangespeakersystems

8. Un‐mutetheappropriateoutputsontheDX0.5.[Seepage15fordetails.]
9. Turn
ontheamplifier(s)ORpoweredloudspeakers.Turnupthevolumeorgaincontrol(s),inmostcircumstancesgain
controlsshouldbeturneduptomaximumsotheamplifiergainmatchesthelevelatwhichlimiterthresholdsinthe
DX0.5havebeenset.
10. Startthesignalsourceandraisethemixer’smain
L/Rfader(s)upuntilaudioisheardthroughtheloudspeakers.
Atthispointthesystemistestedandworking howeverwestronglyencouragethatyoureadtherestofthisowner’smanualto
learnbasicnavigation,howtoedittheinputsandoutputs,setsecurityfeaturesandmore.
ThingstoRemember:
 Neverlistento loudmusicforprolongedperiods.Pleaseseethe SafetyInstructions onpage6 forinformationon
hearingprotection.
 Whenyoushutdowntheequipment,turnofftheamplifiersfirsttopreventthumpsandothernoisesgeneratedby
anyupstreamequipmentfromcomingoutofthespeakers.
Whenpoweringup,turnontheamplifierslast.
 Save the shipping boxes and packing materi als, in the unlikely event of a problem with the DX0.5 these may be
requiredtoshipthedevicetoanauthorisedServiceAgent.
