DX0.5 USERGUIDE
HAM09224UserGuideV1.0 16

…………
Theseseven‐segmentmetersdisplaytheinputandoutputsignallevelsORthegainreductionamountforeachoutput’slimiter,
dependingontheselectedVUMetermode.Detailedinformationmaybefoundonpage20[VUMetersection].
Thesemeters should remain green with the occasional peak into the yellow zone.
If the level staysconstantlyin the yellow
section (or any red clipping), lower the level of the source until feeding the DX0.5 until the metering returns to occasional
excursionsintotheyellow.ItmayalsobenecessarytocheckthegainandEQsettingsontheDX0.5input and
outputchannels.
Inputmeters(startingatthetop)show:
Clip,+15dBu,+9dBu,+3dBu,0dBu,–10dBuand–20dBu.
Outputmeters(startingatthetop)show:
Limit,Clip,+15dBu,+9dBu,+3dBu,0dBuand–15dBuwheninLevelmode.
IftheVUmeter
modeisLimit,theoutputmetersshow:
Limit,0dB,–3dB,–6dB,–9dB,–12dBand–15dB.
17.USB
TheDX0.5maybecontrolledandprogrammedusingaWindows‐basedPC.Gotowww.MartinAudio.com/Softwaretodownload
thefreeapplicationanddriver.HereyouwillalsofindpresetsforotherMartinAudioproductranges
SimplyconnectaUSBcablefromtheDX0.5tothePCinordertocontrolall
parametersoftheprocessorviatheDX0.5Application.
FactoryReset
ItispossibletoresettheDX0.5LoudspeakerManagementSystemtoitsfactorysettings.Pleasekeepinmindthatthiserasesall
settings,includinganypasswordsandpresetsthatmayhavebeenset.Besuretopowerdownanyamplifiersand/orpowered
speakersbeforeresettingtheDX0.5.
Simplypressandhold
theEnter[10],ESC[11]andUtility[12]buttonswhenpoweringupuntiltheLCD
Display[6]shows:
Please Wait....
Memory Reset
Thenyoumaytakeyourfingersoffthebuttons.YouwillknowitworkedwhenthesixoutputMuteLEDs[15]illuminateafterthe
DX0.5isfullypoweredup.
Thedefault
passwordissixzeroes:000000
Utilities
Asmentionedearlier,therearethreemainutilitymenustochoosefrom:
 SystemUtilities
 PresetUtilities
 SecurityUtilities

Withineachutilitymenu,anarrayofsub‐menusareavailable.Wewillgothrougheachutility,eachsubmenu,howtogetthere,
howtoeditandchangesettingsand
whateachControlandbuttondoesineachsituation.
Whennavigatingmenus,thecurrentsettingforanyparameterwillbeindicatedwithanasterisk[*]makingiteasytogetback
whereyoustarted.
PresstheUtilityButton[12]toopentheUtilityMenu.
UsetheNav/Edit1Control[7]
tonavigatebetweenthethreeutilitymenus:SystemUtilities,PresetUtilitiesandSecurityUtilities.
