DX0.5 USERGUIDE
HAM09224UserGuideV1.0 26

…………
 Attack
 Release
 Threshold

UsetheNav/Edit1Control[7]tochangetheattacktime.TurningthisControlclockwiseincreasestheattacktime,whileturning
itanti‐clockwisedecreasestheattacktime.Theattacktimerangesfrom5msto200ms.
Theattacktimeincrementdependsonwhereitiscurrently
set:
 5ms–20ms:±1msperclick
 20ms–30ms:±5msperclick 
 30ms–100ms:±10msperclick
 100ms–200ms:±20msperclick

UsetheEdit2Control[8]tochangetherelease
timeby±0.1sperclick.Tu rningthiscontrolclockwiseincreasesthereleasetime,
whileturningitanti‐clockwisedecreasesthereleasetime.Thereleasetimerangesfrom0.1sto3.0s.
UsetheEdit3Control[9]tochangethethresholdby±0.2dBuperclick.TurningthisControlclockwise
increasesthethreshold,
whileturningitanticlockwisedecreasesthethreshold.Thethresholdrangesfrom–10.0dButo+20.0dBu.Asettingof+20.0dBu
isoff.
PresstheESCbutton[11]toexitlimitereditingmode.
VUMeter
Youmaychoose betweenviewingthesignallevelorthelimiter’sgainreductionforeachoutput.Thesewillbedisplayedonthe
7‐segmentLEDmeters[16].
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenVU-Meter = Level[default]andVU-Meter = Limiter
Act.Ifthelatterisselected,theClipLED
ontheselectedoutput(s)willilluminatetoindicate0dBofgainreduction.Whenthe
signallevelexceedsthelimiterthreshold,thetopLimitLEDwillilluminatetoindicategainreductionisoccurring.AdditionalLEDs
willilluminateforevery3dBofgain reduction.
PresstheESCbutton[11]toaccept
theupdateandexitVUMetereditmode.
LinkingInputsorOutputs
Itispossibletolinkmultipleinputsoroutputsandeditspecificparameterssimultaneously.Thisisusefulifyouwanttosetthe
gainonbothinputsto+1.0dB,forexample.Oryoucouldintroducea3dBcutat250HzonEQband3onoutputchannels1
‐4.
Thissavesvaluabletimeratherthanhavingtomakethesamechangeoneachinputoroutputandofcourseismoreaccurate.
Thechangesareabsolute,notrelative,soifyouwantdifferentvaluesforthesameparameteracrossotherinputsoroutputs,
youneedtoma kethese
changesoneachinputoroutput.Tolink,simplypressandholdanyadditionalinputoroutputMute/
Editbuttons.Anychangedparameterswillaffectalllinkedinputsoroutputs.

