DX0.5 USERGUIDE
HAM09224UserGuideV1.0 24

…………
EQBypassflattensthe 7‐BandEQontheoutputsoyoumayhearexactlyhowitisaffectingthesystem.BytogglingtheEQBypass
onandoff,youmayquicklycomparethesoundwithandwithoutEQ.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenBypass = Off
[default]andBypass = On.
PresstheESCbutton[11]toacceptthenewEQBypassmodeandexittheEQBypasseditingmode.
7‐BandEQ
OutputEQisusedprimarilyforadjustingtheresponseofaparticularloudspeakerortransducer.Additionally,outputEQmaybe
usedtocorrectroomanomaliesinmulti‐roomsetups.
UsetheNav/Edit1[7]Controltochangethefrequency.TurningthisControlclockwiseincreasesthefrequency,whileturningit
anti‐clockwisedecreases
thefrequency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
UsetheEdit2[8]Controltochangethebandwidthby±0.05perclick.TurningthisControlclockwise increasesthebandwidth,
whileturningitanticlockwisedecreasesthebandwidth.TheEQbandmaybeconfiguredashighorlowshelfby
turningitallthe
wayanti‐clockwise.
ThesearetheEQchoicesfromthefurthestanticlockwiseoptiontothefurthestclockwiseoption: 
 –12HighShelving
 –6HighShelving
 –12LowShelving
 –6LowShelving
 0.05–3.00[Parametric]

TochangetheEQbetweenshelvingand
parametric,thegainmustfirstbesetto0.0dB.
UsetheEdit3[9]Controltochangethegainby±0.5dBperclick.TurningthisControlclockwiseincreasesthegain,whileturning
itanti‐clockwisedecreasesthegain.Thegainrangesfrom–15.0dBto+15.0dB.
PresstheESC
button[11]toexittheEQeditingmode.
Delay
Settingupoutput delaysontheDX0.5 isusefulfortime andphasealigning transducersinbi‐ andtri‐amplifiedloudspeakers
systems,aligningsubwooferstofull‐ran geloudspeakers,aligningdelaysystemstomainsonstage,andmore.
Asstatedonpage14,Delaymaybepresentedinoneofthreeways:

 Time(ms),or
 Distance(m)[default],or
 Distance(feet)

UsetheEdit2Control[8]tochangethedelay by:
 ±1.000msperclick,or
 ±0.340mperclick,or
 ±1.115feetperclick

UsetheEdit3Control[9]tochangethedelay by:
 ±0.0208ms
perclick,or
 ±0.007mperclick,or
 ±0.023feetperclick

TurningtheseControlsclockw ise increasesthedelaytime,whileturningthemanti‐clockwisedecreasesthedelaytime.
Theminimumandmaximumdelayrangesfrom:
 0.0000ms–600.9984ms
