Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 17 of 36
5.2 Front Panel Description for 408-M
Name of
Part
Symbol
Function
Increment
Key
 Increment the Value of any
Parameter in edit mode.
 Shuffle to next parameter in the
Sub Menu.
Decrement
Key
 Decrement the Value of any
Parameter in edit mode.
 Shuffle to previous parameter in the
Sub Menu.
 Shows Ambient value for T/C Input
in RUN mode.
SET Key
(Menu /
Enter Key)
 Shows different SET Points, if
pressed in RUN mode.
 It is used to enter in the sub menu.
 It’s used to enter in the edit mode.
 It is also used to save the
parameters to nonvolatile memory,
when user setting a proper data by
Increment and decrement key for
parameter configuration.
PV
(Present
Value)
Display
PV
 4 digital 0.40 inch RED Display
 Display process value.
 Display parameter name when user
set parameter.
 Display Parameter Value when in
Edit mode. (For Single Display
Model Only)
 Display error message when an
error occurs.
