Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 23 of 36
6.4 Calibration Mode
NOTE:-
For Dual Display Device available option for parameter will be displayed on
SV Display in Edit Mode. For Single Display Device available option for
parameter will be displayed on PV Display in Edit Mode.
The retransmission output type is jumper selectable. Thus if current type or
voltage type output, will be decided by the position of the jumper.
Para me ter
(PV di splay )
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
AMB
(Amb)
Ambient
Ambient Adjustment
-
Input is TC
CALZ
(Calz)
Calibration Zero
Calibration Zero for PV Input
(PV/SV Display : Current PV)
-
CALS
(\Cals)
Calibration Span
Calibration Span for PV Input
( PV/SV Display : Current PV)
-
RTZ1
(rtz1)
Retransmission-
1 ZERO
Calibration Zero for Retransmission Output-1
PV/SV Display :
For LC5296, LC5296-H(0.56”) & 5006RN
For Current & Voltage: 0
For LC5296-H(0.8”)
If voltage:-0.000 & If Current:-4.000
-
RTS1
(rts1)
Retransmission-
1 SPAN
Calibration Span for Retransmission Output-1
PV/SV Display :
For LC5296, LC5296-H(0.56”) & 5006RN
For Current & Voltage: 0
For LC5296-H(0.8”)
If voltage:-8.000 & If Current:-20.00
-
RTZ2
(rtz2)
Retransmission-
2 ZERO
Calibration Zero for Retransmission Output-2
PV/SV Display :
For LC5296, LC5296-H(0.56”) & 5006RN
For Current & Voltage: 0
For LC5296-H(0.8”)
If voltage:-0.000 & If Current:-4.000
-
if Device
supports Dual
Retransmission
Output
RTS2
(rts2)
Retransmission-
2 SPAN
Calibration Span for Retransmission Output-2
PV/SV Display :
For LC5296, LC5296-H(0.56”) & 5006RN
For Current & Voltage: 0
For LC5296-H(0.8”)
If voltage:-8.000 & If Current:-20.00
-
if Device
supports Dual
Retransmission
Output
