Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 8 of 36
Protocol
Modbus-RTU
Baud rate
9600, 19200, 38400 bps
2.5 Power Supply
Standard
85-265VAC/ 100-300VDC
Optional
18-36VDC
Power consumption
<10 VA (LC5296/LC5296-H/5006-RN,408-M)
Data backup
Non-volatile memory (can be written up to 100000 times)
Isolation (Withstanding voltage)
 Between primary terminals* and secondary terminals**:
At least 1500 V AC for 1 minute
 Between primary terminals* and grounding terminal:
At least 1500 V AC for 1 minute
 Between grounding terminal and secondary terminals**:
At least 1500 V AC for 1 minute
 Between secondary terminals**:
At least 500 V AC for 1 minute
* Primary terminals indicate power terminals and relay output terminals.
** Secondary terminals indicate analog I/O signal and Communication O/P.
Insulation resistance: 20MΩ or more at 500 V DC between power terminals and
grounding terminal.
2.6 Environmental Conditions
TEMPCO
For Input to PV Display < 100ppm. FOR Display to
Retransmission and Control output < 100ppm
Humidity
20% to 95% RH (Non-Condensing)
Instrument Warm-up Time
Approx. 15 minutes
Ambient temperature
0 to 55°C
Storage Temperature
0 to 80°C
2.7 Advance Feature
 Input scalability for linear input
