Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 7 of 36
2.2 Display & Keys
Model
Display
Specification
LC5296
PV Display
4-Digit, 7-Segment, Red, Character height of 0.56”
SV / Parameter
Display
4-Digit, 7-Segment, Green, Character height of 0.40”
Status Indication
Individual RED Led for Relay & Communication Status
LC5296-H
PV / Parameter
Display
2
4-Digit, 7-Segment, Red, Character height of 0.56”
or
4-Digit, 7-Segment, Red, Character height of 0.8”
Status Indication
Individual RED Led for Relay & Communication Status
5006-RN
PV Display
4-Digit, 7-Segment, Red, Character height of 0.56”
Status Indication
Individual RED Led for Relay & Communication Status
408-M
PV Display
4-Digit, 7-Segment, Red, Character height of 0.8”
LC5248E
PV Display
4-Digit, 7-Segment, Red, Character height of 0.40”
SV / Parameter
Display1
4-Digit, 7-Segment, Green, Character height of 0.28”
Status Indication
Individual RED Leds for Relay Status, Rx,Tx
NOTE:
1. LC5296-H is available with Two Different variant.
 LC5296-H with 0.8” PV Display.
 LC5296-H with 0.56” PV Display.
2.3 Output Types
Relay Output
Relays
2 (Not available in 408-M)
Type
Single Change over
LC5296/LC5296-H/5006-RN : Three Terminals (C, NO, NC)
Rating
2A @ 230VAC / 30VDC
Retransmission Output (For LC5296, LC5296-H, 5006-RN Only)
Number of output
1 / 2 (Specified in Order Code)
Output According to
Process Value
Output Signal
4-20mA / 0-20mA /1-5VDC / 0-10V DC
Load resistance
 For Current o/p
 For Voltage o/p
< 500Ω.
> 3KΩ.
Output accuracy
±0.25% of span
Loop Power Supply (For LC5296, LC5296-H, 5006-RN, 408-M, LC5248E Only)
Supply Voltage
24VDC (±1V) @26mA with Inbuilt Short Circuit
Protection
2.4 Communication Details
Communication (For LC5296, LC5296-H, 5006-RN, LC5248E Only)
Interface
RS485 (2 Wire)
