Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 19 of 36
6.1 Run Time Indication/Function
Following parameters can view or change during run time.
 For Thermocouple input type, Press Decrement key to show ambient temperature.
6.2 Set Point Setting
6.3 Configuration Mode
Parameter
(PV display)
Sett in g nam e and
desc ription
Defaul t
valu e
Shows
only i f
Symbol
Name
ST-1
(st-1)
Set Point 1
Range Depending on PV
sensor type selected
10 0
-
ST-2
(st-2)
Set Point 2
Range Depending on PV
sensor type selected
20 0
-
Parameter
(PV display)
Setting Name & Description
Default Value
Show if Only
Symbol
Name
INPT
(inpt)
INPUT Type
Set PV Input Type
tC j / tC t / tC K / tC r / tC s /
rtd1 / rtd.1 / 0-5v / 1-5v / 0-10
Value
Input Type
Range
0
TC J
-199.9 to 1200 °C
1
TC T
-199.9 to 400 °C
2
TC K
-199.9 to 1372 °C
3
TC R
0 to 1768 °C
4
TC S
0 to 1768 °C
5
RTD
-200 to 850 °C
6
RTD.1
-199.9 to 850.0°C
7
0-5 V/ 0-20
mA*
-1999 to 9999
8
1-5 V / 4-20
mA*
9
0-10 V
*Use external 250ohms,0.1% for
current input
TC K
ZERO
(zero)
Zero
Automatically change to the Input Lower
Range with changing of Input Type
(Refer Above Table)
Can be set to any value within the Input
Range & less the SPAN Value.
-200
(If TC K)
