Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 16 of 36
5.1 Front Panel Description for LC5296, LC5296-H, 5006-RN & LC5248E
 NOTE: Two different variant for LC5296-H are available with different PV
Display size.
 LC5296-H with 0.56” Display & LC5296-H with 0.8” Display
Name of
Part
Symbol
Function
LC5296
5006RN
LC5296-H
Increment
Key
 Increment the Value of any
Parameter.


Decrement
Key
 Decrement the Value of any
Parameter.
 Shows Ambient value for T/C Input
in RUN mode.


SET-1 Key
(Menu /
Enter Key)
 Shows Set Point-1(ST-1), if pressed
in RUN mode.
 In Sub Menu it can be used to get to
the next Parameter.
 It is also used to save the
parameters to nonvolatile memory,
when user setting a proper data by
Increment and decrement key for
parameter configuration.


SET-2 Key
 Shows Set Point-1(ST-2), if pressed
in RUN mode.
 Also used to store modified
SetPoint-2 Value.


PV
(Present
Value)
Display
PV
 4 digital 0.56 inch RED Display
 4 digital 0.8 inch RED Display
(LC5296_0.8”, 408-M Model)
 Display process value.
 Display parameter name when user
set parameter.
 Display Parameter Value when in
Edit mode. (For Single Display
Model Only)
 Display error message when an
error occurs.


SV
(Set
Value)
Display
SV
 4 digital 0.4 inch GREEN
 Display set value.
 Display parameter value of
parameter in process value field
when user set parameter.


Relay-1
Indication
RL1
 ON when Relay-1 is energized &
OFF otherwise.


Relay-2
Indication
RL2
 ON when Relay-2 is energized &
OFF otherwise.


TX
Indication
Tx
 ON when device is transmitting
some Data (RS-485).


RX
Indication
Rx
 ON when device is receiving some
Data (RS-485).


