Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 26 of 36
7.3 Run Time Indication/Function
Following parameters can view or change during run time.
For Thermocouple input type, Press Decrement key to show ambient temperature.
7.5 Configuration Mode
Parameter
(PV display)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
INPT
(INpt)
INPUT Type
Set PV Input Type
tCj1 / tCj.1 / tCK1 / tCk.1 / rtd1 /
rtd.1 / 0-5v /1-5v
Value
Input
Type
Range
0
TCJ1
-200 to 1200 °C
1
TCJ.1
-199.0 to 999.9 °C
2
TCK1
-200 to 1372 °C
3
TCK.1
-199.0 to 999.9 °C
4
RTD1
-200 to 850 °C
5
RTD.1
-199.9 to 850.0 °C
6
0-5V
-1999 to 1999
7
1-5V
-1999 to 1999
*Use external 250ohms,0.1% for current
input
5
(RTD.1)
ZERO
(zero)
Zero
Automatically change to the Input Lower
Range with changing of Input Type
(Refer Above Table)
Can be set to any value within the Input Range
& less the SPAN Value.
-199.9
(If RTD.1)
SPAN
(spaN)
Span
Automatically change to the Input Higher
Range with changing of Input Type
(Refer Above Table)
Can be set to any value within the Input Range
& greater the ZERO Value.
850.0
(If RTD.1)
DP
(dp)
Decimal Point
Set position of Decimal Point on Display.
0 / 0.0 / 0.00 / 0.000
0 : 0
1 : 0.0
2 : 0.00
3 : 0.000
0
Input Type is
Linear
BRHT
(brHt)
Brightness
Adjust Brightness of the 7-segment Display.
10 to 100
50
PASS
(pass)
Password
Set Device Password
0 to 9999
1
