Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 31 of 36
16
Hysteresis 1
40016
Int
R + W


17
Hysteresis 2
40017
Int
R + W


18
Pass word
40018
Int
R + W


19
Set Value 1
40019
Int
R + W


20
Set Value 2
40020
Int
R + W


21
INLO
40021
Int
R + W


22
INHI
40022
Int
R + W


10.3 Exceptional Response
CODE
MEANING
01
Function code Invalid. It must be 01, 05, 03 or 06.The function code received in
the query is not allowable action for the slave.
02
Illegal address value. The data address received in the query is not an
allowable address for the salve.
03
Illegal data value. A value contained in the query data field is not an allowable
value for the salve.
06
When Master device write some parameters to Slave device, If slave device
busy then it will send 06 code to indicate slave device is busy.
TABLE – 8
Note: 1. Refer Menu Mode Description Table the value & Range of each
Parameter.
EX: Input Type (Applicable Range : 0 to 9):
Input Type
Value
J-tc
0
T-tc
1
K-tc
2
R-tc
3
S-tc
4
Rtd
5
Rtd.1
6
0 – 5V
7
1 – 5V
8
0 – 10V
9
