Masibus LC5296 User Manual

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 35 of 36
LC5248E
Jumper setting for Communication
There are mainly Two types of Retransmission Output is available:
o Voltage (0-10VDC, 0-5VDC, 1-5VDC)
o Current (4-20mADC, 0-20mADC)
 This can be Settable by changing the Position of Shorting Link Jumpers on
Retransmission Add-on Card shown in below figure.
Jumper Setting for Retransmission card: m61Cao201
Jumper Setting for Retransmission card: m61Cao102
Jumper Setting for Retransmission card: m49Acp101
