O3 Regional Oximeter Chapter 4: Operation
www.masimo.com 28 Masimo
Ref. Feature Description
Configurator
Press “-” to shorten and “+” to lengthen the time frame of the
trending displayed.
9 rSO
2
Alarm Limits Indicates the selected high and low limit values which triggers an
rSO
2
alarm. Press the value to access the rSO
2
menu.
10
ΔSpO2%
Displays the difference between levels of SpO2 (peripheral SpO2
sensor site) and rSO
2
of the O3 Sensor site.
11 AUC Displays the Area Under the Curve cumulative index.
12 Timeline Displays timestamps and corresponding date.
13
Δbase%
Displays the current difference between levels of rSO
2
and selected
baseline rSO
2
. Also displays the unit of measurement (%).
Press the value to access the Delta Baseline menu.
14 Y-axis Shows the current view range for rSO
2
. Press the axis to customize
the viewing range for rSO
2
.
15 Baseline Indicator Indicates the baseline rSO
2
value selected by the user.
1
From the pulse oximetry sensor connected to the Radical-7
®
in the Root device.
