O3 Regional Oximeter Chapter 4: Operation
www.masimo.com 29 Masimo
Baseline View
In the Baseline view, the baseline rSO
2
is seen as a horizontal yellow line across the entire
trend display. To enable/disable Baseline View, tap the drop-down menu on the top right
corner of the O3 Module window. Press the Baseline View button to enable or disable
Baseline View.
Ref.
Feature Description
1 Baseline Indicator Indicates the baseline rSO
2
value selected by the user.
2 Baseline Displays Baseline across the Trend area.
The Baseline View is displayed only when Set Baseline has been enabled. The Baseline can be
enabled in two ways:
1. Tap the drop-down menu on the top right corner of the O3 Module window. Press
the Set Baseline button to enable the baseline for the sensors.
Or
2. Press the Gear icon on the lower right corner of the main window of Root to access
the Main Menu, then press the O3 icon to access the O3 Module Menu and select
the Set Baseline menu. In the Set Baseline menu, select Enable. Press Ok to
confirm and press the Home button to return to the Main Window.
CAUTION: Reset Baseline for each new patient monitored, if applicable.
Note: Configuration for this option does not hold through power cycle.
