www.masimo.com 23 Masimo
Chapter 3: Basic Setup and Use
Before the Rad-5/5v Handheld Pulse Oximeter can be used in a clinical setting, it needs to
be inspected; properly setup and the batteries need to be installed. This chapter contains
information about setting up Rad-5/5v before use.
Unpacking and Inspection
Remove the device from the package and check for signs of damage. Check all items against
the packing list. Save all packing materials, invoice and shipping labels. These items may be
required to process a claim with the carrier.
If anything is missing or damaged, contact the Technical Service Department. See
Contacting Masimo on page 61.
Initial Setup
The following information describes the preparation and set-up of the Rad-5/5v.
1. Inspect the device case for damage.
2. Install four new AA alkaline batteries. See Battery Installation and Replacement
on page 57.
3. Verify the device powers-up when the batteries are installed.
4. Press and hold the Power On/Off Button for 2-seconds to turn the oximeter off.
See Front View on page 19.
5. Press the Power On/Off Button to turn the device on again. Verify all LEDs light
up and that the speaker makes a brief sound.
6. Connect the cable and/or sensor to the Rad-5/5v.
Refer to Basic Use on page 23 for steps to verify proper operation of the device.
Basic Use
These steps are to be performed after performing the initial setup steps.
1. Connect a Red Direct Connect Spot Check Sensor or patient cable to the Patient
Cable connector of the device. See Front View on page 19. Check that the cable is
secure, and not twisted or damaged.
Note: Select a sensor that is compatible with the device before attaching it to
the patient or connecting it to the patient cable. See the Directions for Use for
the sensor.
2. Attach the sensor to the patient. Refer to the Directions for Use for the sensor to
properly apply the sensor.
3. Connect the sensor to the patient cable.
4. Press the Power button to turn the device on. All front-panel LEDs momentarily
illuminate and a one-second tone is heard. See Front View on page 19.
