Masimo Rad-5 User Manual

Rad-5/5v Chapter 7: Specifications
www.masimo.com 49 Masimo
Physical Characteristics
Physical Characteristics
Dimensions
15.8 cm x 7.6 cm x 3.6 cm
(6.2” x 3.0” x 1.4”)
Weight
0.32 kg. (13 oz.)
Modes
Modes
Rad-5
Averaging Mode
2, 4, 8, 10, 12, or 16 seconds [7]
Sensitivity
Normal, Maximum and APOD
Rad-5v
Averaging Mode
8 seconds
Sensitivity
Normal
Alarms
Alarm
Details
High Priority
799 Hz tone, 5 pulse burst, pulse spacing: 0.250s, 0.250s, 0.500s, 0.250s,
repeat time:10s
Low Priority
432 Hz tone, 3 pulses, repeat time: 5s
Alarm
Volume
High Priority: 75 dB (max), Low Priority: 75 dB (max)

Masimo Rad-5 Specifications

General

Type	Handheld Pulse Oximeter
SpO2 Range	0% to 100%
Pulse Rate Range	25 to 240 BPM
Perfusion Index Range	0.02% to 20%
Power Source	4 AA Alkaline Batteries
Operating Temperature	5°C to 40°C
Humidity	5% to 95% non-condensing
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
