Masimo Rad-5 User Manual

Rad-5/5v Chapter 7: Specifications
www.masimo.com 50 Masimo
Display/Indicators
Display/Indicator
Description
Data Display
Rad5/Rad5v
%SpO
2
, pulse rate, alarm status, alarm silenced status, Signal IQ/pleth
bar, perfusion index bar, battery status
Rad-5 Only
MAX, FastSat
Indicator Type
LED
Compliance
EMC Compliance
IEC 60601-1 2, Class B
Safety Standards Compliance
ANSI/AAMI ES 60601-1:2005+A1:2012
CAN/CSA C22.2 No. 60601-1:2014
IEC 60601-1:2005+A1:2012
EN/ISO 80601-2-61:2011
IEC 60601-1-8:2006+A1:2012 (Rad-5 only)
Equipment Classification per IEC 60601-1
Type of Protection
Internally powered (Battery power)

Masimo Rad-5 Specifications

General

Type	Handheld Pulse Oximeter
SpO2 Range	0% to 100%
Pulse Rate Range	25 to 240 BPM
Perfusion Index Range	0.02% to 20%
Power Source	4 AA Alkaline Batteries
Operating Temperature	5°C to 40°C
Humidity	5% to 95% non-condensing
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
