Masimo Rad-5 User Manual

Rad-5/5v Chapter 4: Operation
www.masimo.com 37 Masimo
Buttons
Settings
+
Standard Mode
Use Up or Down Arrow
Keys to adjust parameter
to desired setting.
Note: The parameter is
set/selected when the
Mode/Enter and Next
buttons are pressed.
Sleep Mode
(SLP)
LED Display
Brightness (4 levels)
Note: Only available
indicators
illuminate while
adjusting setting.

Masimo Rad-5 Specifications

General

Type	Handheld Pulse Oximeter
SpO2 Range	0% to 100%
Pulse Rate Range	25 to 240 BPM
Perfusion Index Range	0.02% to 20%
Power Source	4 AA Alkaline Batteries
Operating Temperature	5°C to 40°C
Humidity	5% to 95% non-condensing
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
