Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 28
ANALOG MODE
MODE
NO
LIST
DESCRIPTION
SETTING
A
N
A
L
O
G
M
O
D
E
25
Sync On Green
Set up the G(Green) Video added horizontal, vertical sync
frequency or not
No=0
Yes=1
26
HS Out Terminal
<= CS
Set the Horizontal Sync port, with adding Vertical Sync or not
No=0
Yes=1
27
VS Out Terminal Off
Set the Vertical Sync port, with adding Vertical Sync or not.
No=0
Yes=1
28
DPMS Video
Selecting the video signal output or not, when the DPMS is
operating
On=0
Off=1
29
DPMS_Hsync
DPMS is a mode for power saving at the monitor
On=0
L_Off=1
H_Off=2
30
DPMS_Vsync
DPMS is a mode for power saving at the monitor
On=0
L_Off=1
H_Off=2
31
DVI Out
Selecting the DVI output signal
D&A=0
Digital=1
Analog=2
32
DVI Range
Setting of the Digital output signal to Full/Limit Range
Full=0
Limit=1
RBLv.240=2
33
Video Level
Set video level mV
0~999mV
(default 700mV)
34
Sync Off
H/V/Sync & Data enable Off setting
Sync On=0
H-Sync off=1
V-Sync off=2
Data enable off=4
H/V-Sync off=3
Data enable & H/V-Sync off=7
35
Link Rate(DP)
Setting to DISPLAYPORT link rate
Default Auto=0
1.63G=1 / 2.7G=2 / 5.4G=3
6.75G=4 / 8.1G=5
36
Link Count(DP)
Setting to DISPLAYPORT link count
Default Auto=0
1Lane=1 / 2Lane=2 / 4Lane=3
