Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 30
D
I
G
I
T
A
L
M
O
D
E
12G=12
32
FRL Lane
Setting to FRL Lane
3Lane=3
4Lane=4
33
FRL Mode
EDID Check  Read EDID on TV(Monitor) and if
TV(monitor) not support to SCDC then no screen output
EDID Pass  Screen output regardless of SCDC
SCDC Chk=0
SCDC
non Chk.=1
34
Displayport
Link Rate
Setting to Displayport link rate
0~5
Default / Displayport link rate to auto setting
Auto=0
Setting Displayport link rate to 1.62Gbps
1.62Gbps=1
Setting Displayport link rate to 2.70Gbps
2.70Gbps=2
Setting Displayport link rate to 5.40Gbps
5.40Gbps=3
Setting Displayport link rate to 6.75Gbps
6.75Gbps=4
Setting Displayport link rate to 8.10Gbps
8.10Gbps=5
35
Displayport
Lane Count
Setting to Displayport lane count
0~4
Default / Auto Displayport lane setting
Auto=0
Setting Displayport to 1(one) lane
1lane=1
Setting Displayport to 2(two) lane
2lane=2
Setting Displayport to 4(four) lane
4lane=4
36
Sync off
Setting to Sync Off
Default / Setting to Horizontal & Vertical & DE sync on
On=0
Setting to Horizontal sync off
H-sync off=1
Setting to Vertical sync off
V-Sync off=2
Setting to Data Enable off
DE off=4
Setting to Horizontal & Vertical sync & DE off
H&V&DE off=7
37
Video Format
2D or 3D setting
0 or 2
Default / 3D setting off
Off=0
3D display setting
3D=2
38
3D Structure
3D Type setting
0~8
Frame Packing(3D data: 0000)
0
Field Alternative(3D data: 0001)
1
Line Alternative(3D data: 0010)
2
Side-By-Side Full(3D data: 0011)
3
Reserved
4
Reserved
5
Top and Bottom(3D data: 0110)
6
Side-By-Side Half(3D data: 1000)
8
39
3D Ext Data
3D Ext Data setting
0~7
