Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 31
D
I
G
I
T
A
L
M
O
D
E
Horizontal sub-sampling odd/left picture, odd/right picture
0
Horizontal sub-sampling odd/left picture, even/right picture
1
Horizontal sub-sampling even/left picture, odd/right picture
2
Horizontal sub-sampling even/left picture, even/right picture
3
Quincunx matrix odd/left picture, odd/right picture
4
Quincunx matrix odd/left picture, even/right picture
5
Quincunx matrix even/left picture, odd/right picture
6
Quincunx matrix even/left picture, even/right picture
7
40
3D Vact_space/Vblank3
3D V Active Space setting
Line
41
Frame packing interlace
Frame packing interlace setting
0 or 1
Default / Frame packing interlace off
Off=0
Frame packing interlace on
On=1
42
HDR EOTF
Setting to HDR
0/2/3
Setting to HDR off
Off=0
Setting to HDR10 on Setting to HDR10 on
[HDR 10 default setting value]
a. On/Off HDR Metadata infoframe:1_On/Enable
b. Type of HDR Metadata infoframe: 7_Fixed, un editable
c. Version of HDR Metadata infoframe: 1_Version 1, Fixed, un editable
d. Select EOTF: 2_SMPTE ST 2048
e. Type of static Metadata Descriptor ID:0_Metadata type1
f. Set Display_Primaries_X[0]: 35000
g. Set Display_Primaries_Y[0]: 15000
h. Set Display_Primaries_X[1]: 7500
i. Set Display_Primaries_Y[1]: 40000
j. Set Display_Primaries_X[2]: 7000
k. Set Display_Primaries_Y[2]: 2500
l. Set White_point_X: 13550
m. Set White_point_Y: 13500
n. Set max_display_mastering_luminance: 10000
o. Set min_display_metering_luminance: 70
p. Set Maximum Content Light Level: 1000
Set Maximum Frame-average Light Level: 400
HDR10=2
Setting to HLG on
HGL=3
43
HDR Max CLL
Setting to HDR Max CLL
1~65535
44
HDR Max FALL
Setting to HDR Max FALL
1~65535
