Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 32
COMPONENT MODE
MODE
NO
LIST
DESCRIPTION
SETTING
C
O
M
P
O
N
E
N
T
M
O
D
E
25
Serration On of DTV
DTV serration on/off setting
0 or 1
DTV serration off
No=0
DTV serration on
Yes=1
26
Serration Pulse
Serration pulse setting
0 or 1
DTV serration setting to HS/2
HS/2=0
DTV serration setting to HS
HS=1
27
Number of EQP Pulse
(Front EA)
Select the number of EQP pulse in vertical front
porch
0~99
28
Number of EQP Pulse
(Back EA)
Select the number of EQP pulse in vertical back
porch
0~99
29
Sync On(Pb&Pr) with Y
Select the sync signal with Pb & Pr
0 or 1
Sync signal with Pb & Pr
0
Sync signal without Pb & Pr
1
30
(Pb & PR) Out Level
Set of Pb & Pr signal level
0~100%
31
Sync Set
0=Tri Level: Output with antagonism sync
Tri Lev=0
1=Bi Level: Output with general sync
Bi Lev=1
