Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 47
2: Flicker OSD only
2
3: Flicker character and OSD
3
4: Flicker color only
4
5: Flicker character and color
5
6: Flicker OSD and color
6
7: Flicker character, OSD and color
7
22
Flicker on time (0~999)/Vf
Flicker on/off time set up to 0~999/Vertical frequency
*If you want to check flicker pattern, you have to set up flicker
on and off time together.
0~999
23
Flicker off time (0~999)/Vf
0~999
24
Gamma Correction (0~30)/10
Analog gamma correction (0~30)/10
0~30
25
Video R (On=0, Off=1)
Video red on/off option
0=on
1=off
26
Video G (On=0, Off=1)
Video green on/off option
0=on
1=off
27
Video B (On=0, Off=1)
Video blue on/off option
0=on
1=off
28
Video Level (0~999mV)
Video level set up
0~999
29
Scart
Scart set up
1=RF
2=CVBS
3=RGB
4=Y/C,+1
30
Reserved
31
Reserved
32
Reserved
33
Reserved
34
Reserved
