Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 48
4) How to modify the pattern  Call pattern No. xxx and press EDIT button.
① Full white pattern No.503 edit value and result.
Ref.no 503
Full White pattern
1.Color box H start
100
100
100
50
2.Color box V start
100
100
100
0
3.Color box H size
100
100
50
100
4.Color box V size
100
100
50
100
5.Color Box R Level
255
255
0
255
6.Color Box G Level
255
0
255
0
7.Color Box B Level
255
0
0
0
8.Uniformity Position No.
0
0
0
0
9.Uniformity Position size
0
0
0
0
10.Lip_Sync on
0
0
0
0
11.Lip_Sync off
0
0
0
0
12.Cross Hatch H Divide
0
0
0
0
② Full white pattern No.505 edit value and result.
Ref.no 504
Gray Step pattern
1.Color Step
256
8
8
8
2.Color Step Case
3
3
3
1
3.Red Color Level
255
255
0
0
4.Green Color Level
255
255
0
0
5.Blue Color Level
255
255
255
255
