model no. 046-0266-0 | contact us 1-800-689-9928
12
ASSEMBLE THE T-RAIL
ASSEMBLE THE T-RAIL
Connect the T-Rail Sections
Align the 4 T-Rail sections on the floor. Connect these rails together with the rail couplers as shown.
All rail pieces must be aligned properly.
