49
BACKUP BATTERY
headline bars
continuation tabs
notes
warnings
BACKUP BATTERY
Press the latch inwards to release the cover.
Remove the cover.
Take out the battery and connect the wires to the battery terminal tabs, being careful to match
the polarity.
Red wire connects to red terminal tab (+).
Black wire connects to the black terminal tab (-).
Place the battery back into the battery compartment.
Close the cover.
Install the Metal Hanger
Unplug the garage door opener from power
before proceeding.
Use the screws and nuts to mount the metal
hanger to the operator mounting plate.
Affix a cushion at the side of the hanger.
Install the backup battery unit to the metal
hanger.
