model no. 046-0266-0 | contact us 1-800-689-9928
INSTALL THE HEADER BRACKET
Attach a 2x4 (if necessary)
If the calculated header bracket is above the door header, attach a 2x4 between two studs to install the
header bracket.
Mark Above the Highest Point of Travel
Mark a spot on the
centreline of the garage
door, 1 1/4” (3 cm) above
the highest point of travel
of the garage door.
Mark a spot on the
centreline of the garage
door, 7” (18 cm) above
the highest point of
travel of the garage
door.
One-Piece Jamb Door
Highest point of travel
1 1/4” (3 cm) above highest
point of travel
7” (18 cm)
1 1/4” ( 3 cm)
Sectional Door
Door header
Use lag screws (not included) to
attach the 2x4.
