model no. 046-0266-0 | contact us 1-800-689-9928
HANG THE OPENER
Attach the Hanging Brackets
Hanging brackets should be angled to provide rigid support. Measure the distance from the motor unit to
the structural support. Cut and bend the hanging brackets as required.
For an “open-seam” garage, attach the hanging brackets directly to the joists with 2 lag screws.
Bracket (not included)
Bolts and Nuts (not included)
On a finished ceiling, attach a sturdy metal bracket (not included) to structural supports before installing
the opener.
Attach the Opener to the Hanging Brackets
Ensure the T-rail is centred over the door. Remove the 2x4.
WARNING
• To avoid possible serious injury from a falling garage door opener, fasten it securely to structural
supports of the garage. Concrete anchors must be used if installing any brackets into masonry.
To Next Page
