model no. 046-0266-0 | contact us 1-800-689-9928
INSTALL THE DOOR BRACKET
CAUTION
• Lightweight garage doors are not designed for use with garage door opener must be equipped with
a door reinforcement kit. Check with the garage door manufacturer for more information. Many door
reinforcement kits provide for direct attachment of the clevis pin and door arm. In this case, you will
not need the door bracket, proceed to “Install the Door Arms” section.
One-Piece Wood Doors
For wood doors, drill 5/16" (8 mm) holes through the door and secure
bracket with 5/16 x 2" (8 x 50 mm) carriage bolts, lock washers and nuts
(not included).
One-Piece Metal Doors
Drill two 3/16" (5 mm) pilot holes. Use 2 self-threading screws to secure the
door bracket.
Centre the door bracket on
the top of the door.
Bolt 5/16 x 2" (8 x 50 mm)
(not included)
