C2 x 4
Wire Clip (Optional)
C3 x 20
Wire Holder
C5 x 4
Wood Screw
BAG C
B6 x 3
Hitch Pin
B8 x 4
Locknut
B4 x 1
Clevis Pin
B5 x 1
Clevis Pin
B9 x 1
Clevis Pin
9
WHAT IS INCLUDED
headline bars
continuation tabs
notes
warnings
BAG B
B1 x 4
Lag Screw
B2 x 4
Bolt
B3 x 2
Self-tapping Screw
BAG A
A1 x 12
Carriage Bolt
A2 x 12
Locknut
A3 x 2
Bolt
A4 x 3
Locknut
A5 x 3
Flange Bolt
