Mastervolt Masterlink BTM III User Manual

FIRST START-UP
14 November 2006 / Masterlink BTM-III / EN
5.2.2 Settings for battery bank 1 (Service
battery)
The following parameters must be adjusted for the
service battery (battery bank 1):
• Name of the battery bank; example: POWER
BANK
• Nominal battery voltage; example: 24V
• Nominal capacity of the installed batteries;
example: 225Ah
NOTE: displayed values may differ
Steps:
Hold Select pressed for
3 seconds until
“HISTORICAL” is
displayed.
Press Select once:
BANK 1 is shown.
Then press Set to enter
the settings menu for
battery bank 1
BATTERY NAME is
displayed
Press Set repeatedly to
choose the desired
name.
Then press Select to
proceed.
Now BANK VOLTAGE
is displayed
If necessary, press Set
to adjust.
Then press Select,
BATTERY CAP will be
displayed
Now adjust this value
in accordance with the
batteries installed
(battery bank 1) See
also chapter 5.2.1.
After adjusting the
capacity press Select
repeatedly until EXIT
LEVEL is displayed
By pressing Set you
will return to the initial
menu
26.00V - 0.0A
100% ---:--
Select
3 sec.
HISTORICAL
SET TO ENTER
BANK 1
SET TO ENTER
Set
Select
BATTERY NAME
SERVICE BANK
Set
x times
BATTERY NAME
POWER BANK
Select
BATTERY CAP
225 Ah Ç
Select
x times
EXIT LEVEL
PRESS SET
Set.
26.00V - 0.0A
100% ---:--
BANK VOLTAGE
24V
Select
BATTERY CAP
200 Ah Ç
Set
x times
BANK VOLTAGE
12V
Set
