ADDITIONAL INFORMATION
EN / Masterlink BTM-III / November 2006 31
11.8 BATTERY NAMES
See chapter 5.2 and 9.1 for settings. Available names for the battery banks are:
Battery bank 1 Battery bank 2 Battery bank 3
SERVICE BANK NOT USED AUTO BACKLIGHT
STARTER BANK SERVICE BANK NOT USED
HOUSE BANK STARTER BANK SERVICE BANK
PORT BANK HOUSE BANK STARTER BANK
STARBOARD BANK PORT BANK HOUSE BANK
POWER BANK STARBOARD BANK PORT BANK
GEN.START BANK POWER BANK STARBOARD BANK
BOWTHRUST BANK GEN.START BANK POWER BANK
RADIO BANK BOWTHRUST BANK GEN.START BANK
12V SERVICES RADIO BANK BOWTHRUST BANK
OTHER BANK 12V SERVICES RADIO BANK
OTHER BANK 12V SERVICES
OTHER BANK
11.9 NMEA0183 FORMAT
The NMEA0183 format of the Masterlink BTM-III shows: $PMVBM,3,27.3,V,0000.2,A,100,%,00.0,V,00.0,V*70
PMV Proprietary format Mastervolt
BM Battery Monitor
3 Version 3 (for three battery banks)
27.3V Voltage battery bank 1
0000.2A Charge current battery bank 1
100% SOC battery bank 1 100%
00.0V Voltage battery bank 2
00.0V Voltage battery bank 3
*70 Checksum according to NMAE0183 requirements
11.10 ORDERING INFORMATION
Part number Description
70904610 Grey installation housing *
39019052 Single shunt 500A/50mV*
70904180 Single shunt 1000A/100mV
21730100 PC link RS232-QRS232 (without galvanic isolation)
21730300 PC link RS232-QRS232 ISOLATED (with galvanic isolation)
6801601100 Cable 3x2x0.25 mm² twisted stranded wires (per meter)
6801601200 Cable 4x2x0.25 mm² twisted stranded wires (per meter)
6801601300 Cable 5x2x0.25 mm² twisted stranded wires (per meter)
6502001030 Modular RJ 12/ cross wired communication cable (6 m. / 19 ft.)
6502100100 Modular RJ 12/ cross wired communication cable (10 m. / 33 ft.)
6502100150 Modular RJ 12/ cross wired communication cable (15 m. / 48 ft.)
* These parts are standard included with the delivery of the Masterlink BTM-III
Mastervolt can offer a wide range of products for your electrical installation, including AGM batteries, GEL
batteries, DC distribution kits, battery switches, battery cables, battery terminals and Mastervision switchboards
See our website www.mastervolt.com for an extensive overview of all our products and free to download software
for remote monitoring (see chapter 11.6)
