MATO MTS600R - 14 ． Specifications

MTS600 Instruction Manual
88
14.Specifications
Telescope
Aperture: 45mm
Magnification: 30×
Image: Erect
Field of view: 1°30′
Minimum focus: 1.5m
Distance Measurement
Measuring range:
Reflectorless: *1
MTS-602R 200m *2
MTS-605R 200m *2
Reflective sheet: *3
MTS-602R 800m
MTS-605R 800m
Single prism: *3
MTS-602R --5.0km
MTS-602 ----2.0km
MTS-605R ---3.0km
MTS-605 ----2.0km
Three prisms: *3:
MTS-602 -----3.0km
MTS-605 -----3.0km
Accuracy :
MTS-602 (R) --- ±(2+2×10
-6
·D) mm *4
MTS-605 (R) --- ±(2+2×10
-6
·D) mm *4
Minimum display :
Fine measurement : 1mm
Rapid measurement : 1mm
Tracking measurement : 1mm
Measuring time :
Fine measurement (repeat) : about 1.8sec.(first time2.5sec.)
Rapid measurement(repeat) : about 0.9sec.(first time 2.5sec.)
Tracking measurement : about 0.4sec.(first time 1.5sec.)
Atmospheric correction :
ppm input range : -499×10
-6
~+499×10
-6
（step 1×10
-6
）
Prism constant correction : -99×10
-6
~+99×10
-6
(step 1×10
-6
)
