Matrix E1X Service Manual

53
CHAPTER 8: ELLIPTICAL TRAINER SPECIFICATIONS AND ASSEMBLY GUIDE
8.1 ELLIPTICAL SPECIFICATIONS
CONSOLE
Display Screen WorkoutProfileWindow-7"bluebacklitgraphicLCDdisplay
InstructionCenter-14characterredLEDalphanumericdisplay
InformationalDisplay-3numeric7segmentdisplay(3sets)
Display Readout Time, Distance, Calories, Speed, Level, Watts, METS, Heart Rate, Profile
Programs Manual, Hill Interval, Random Interval, Time Goal, Distance Goal,
Calories Goal, Constant Watts, Random, Target HR, Weight Loss, Fit
Test, Warm Up, Cool Down.
On-the-flyProgramChange Yes
Telemetric HR Receiver Yes
Contact HR Sensors Yes
Program Quick Keys Yes
One-TouchQuickStart Yes
Pause Time 30 Seconds
Language Options English, Italian, German, Spanish, French, Dutch, Portuguese, Japanese
TECHNICAL DATA
Resistance Technology JID™ Hybrid Generator
Resistance Levels 20
Drive System Two stage belt driven
Stride Drive System Forward and Reverse
Stride Length 19" / 48 cm
Dimensions (L x W x H) 83" x 31" x 67" / 211 x 79 x 170 cm
Product Weight 333 lbs / 151 kg
Max User Weight 400 lbs / 182 kg
Power Requirements Self Powered
SPECIAL FEATURES
Handlebar Design Multi position dual action arms and ergo bend stationary
Thumb Switch Controls Yes, equipped in the dual action arms
Pedals Auto positioning pedals with front safety fences
Integrated Reading Rack Yes
Q-factor 3.75"
ENTERTAINMENT SOLUTIONS
FITCONNEXION™ Ready Yes
Networking Capabilities CSAFE Ready, Fitlinxx™ certified
