PIPETTOR REASSEMBLY
12 /
Autoclaving
To keep the tubing free from ejector contact, rotate the
manifold plate and tubing one complete turn
counterclockwise (see Figure 11). Insert the manifold
assembly into the main housing support ribs.
Figure 11: Rotating Manifold Assembly
4. Slide the ejector comb over the tip fittings with the slots on
the back of the comb exposed (see Figure 12).
Figure 12: Attaching Ejector Comb
