Main Stream and Sub Stream
This options enables the user to set the streaming parameters for the defined cameras. Configure the parameters
for the Main Stream and Sub Stream as described below:
Video Encoding: Select the video encoding mode from the drop-down list.
FrameRate: Select the video frame rate from the drop-down list. The maximum frame rate that can be set for a
camera is 30.
Resolution: Select the required resolution from the drop-down list.
The stream resolution of selected IP Camera will display in the Resolution list. In case if the user has
configured the ROI (Region Of Interest) into the running stream profile of IP Camera then, the Stream
resolution of that particular stream will display into the resolution list.
The custom resolution of minimum 64pixels and maximum 8192pixels can be played in the Live View.
The VGA resolution, that is 640x480 is supported in all Matrix Cameras supported by NVR/NVRX, except
the following:
• SATATYA CIBR13FL40CW
• SATATYA CIDR13FL40CW
• SATATYA CIDRP20VL130CW
• SATATYA CIBR30FL36CG
• SATATYA CIBR30FL60CG
• SATATYA CIDR30FL36CW
• SATATYA CIDR30FL60CW
Bit Rate Type: Select the Constant Bit Rate (CBR) or Variable Bit Rate (VBR).
Bit Rate: Select the required Bit Rate from the drop-down list.
Quality: Select the video quality from the drop-down list. Selecting higher settings will give you higher quality video,
at the expense of network bandwidth and disk storage capacity.
GOP: Select the Group of Pictures (GOP) from the drop-down list.
Audio: This option allows the user to activate or inactivate Audio in synchronization with the video for stream type
of selected camera.
Search Camera
As per the configuration of the LAN parameter, the cameras in the network will start appearing in this page. The
Cameras with identified IP Address, Brand Name and Model Name appears in the list as shown below:
