Matrix SATATYA NVR0801X System Manual

290 Matrix SATATYA Devices Manual
Device Sensor Input Settings
To configure the Input Settings, Click on Configuration option in the left pane of the device client page. Click on
Device I/O Settings and select Sensor Input. The page appears as shown below.
• Select the Sensor Input Number from the drop-down list.
• Click on the check box to Enable the Input.
• Specify a user friendly Name for the input for easy identification.
• The Mode Parameter allows selection of Normally Open (NO) or Normally Closed (NC) option based on
the input required. This is dependent on the contacts of detector or alarm panel that is connected to this
port.
• The Delay Time defines the minimum time an input must be in a given state i.e up or down, before being
reported. For example, if a Normal state is changed to Alarm, the state must remain in Alarm for the
specified seconds before an Alarm state is generated. Select the appropriate delay time in seconds for the
selected input as per the site requirements.
• Click on Save once done.
