80 Matrix SATATYA Devices Manual
11. Mount the hard disk in HDD fitting plate. Connect the SATA Cable to the disk and connect the other end to the
mother board.
12.Connect the Power Cable to the disk. Screw the disk holders in place inside the unit using 3 screws on the front
plate of HDD fitting plate using a magnetic screw driver
13. Replace the cover and screw it back into place. Power up the SATATYA HVR. The system will now
automatically detect and format the new disk(s).
Apply power to the HVR only after you have completed the entire installation.

Matrix SATATYA NVR0801X Specifications

General

Brand	Matrix
Model	SATATYA NVR0801X
Category	DVR
Language	English
