126 Matrix SETU ATA211 V1 System Manual
Where,
Cont. = continuous
Please note that frequency and cadence for following tones are same and fixed for all countries:
• Confirmation Tone: 400Hz, 0.1 on - 0.1 off
• Programming Tone: 400Hz, 0.1 on - 0.9 off
• CCWT: 400Hz, 0.3 on 6.0 off
• Routing Tone: 400Hz, 0.1 on 1.9 off
• Prompt Tone: 400 Hz, 0.1on - 0.1off - 0.1on - 2.0off
If the ATA211 is defaulted, CPTG parameters will not get default values.
Rings
During an incoming call, the system will play the ring over SLT as per the ring cadence specified for the country.
User can select the name of the country from the list of countries. By default. INDIA is selected. For list of country
specific 'Ring', refer 'Table-2'.
Table 2: (Ring Cadences)
29 Thailand 400*50 cont. 400 1.0on 4.0off 400 0.5on 0.5off 400 0.3on 0.3off 400 1on 1off
30 Turkey 450 cont. 450 2.0on 4.0off 450 0.5on 0.5off 450
0.2on 0.2off
0.6on 0.2off
450 1on 1off
31 UAE 350+440 cont. 400+450
0.4on 0.2off
0.4on 2.0off
400
0.375on
0.375off
400
0.4on 0.35off
0.225on
0.525off
400 1on 1off
32 UK 350+440 cont. 400+450
0.4on 0.2off
0.4on 2.0off
400
0.375on
0.375off
400
0.4on 0.35off
0.225on
0.525off
400 1on 1off
33
USA/
Canada
350+440 cont. 440+480 2.0on 4.0off
480+62
0
0.5on 0.5off 480+620
0.25on
0.25off
480+620 1on 1off
Code Country
Frequency
(Hz)
CADENCE (In Seconds)
T1ON T1OFF T2ON T2OFF
01 Australia 25 0.4 0.2 0.4 2.0
02 Belgium 25 1.0 3.0
03 Brazil 25 1.0 4.0
04 China 25 1.0 3.0
05 Egypt 25 2.0 4.0
06 France 25 1.5 3.5
07 Germany 25 3.5 5.5 0.79 1.1
08 Greece 25 1.0 4.0
09 India 25 0.4 0.2 0.4 2.0
10 Israel 25 2.0 3.0
11 Italy 25 1.0 4.0
12 Japan 25 1.0 2.0
13 Korea 25 1.0 3.0
14 Malaysia 25 2.0 3.0
15 New Zealand 25 2.0 3.0
Code Country
Dial Tone Ring Back Tone Busy Tone Error Tone1 Error Tone2
Freq. Cadence Freq. Cadence Freq. Cadence Freq. Cadence Freq. Cadence
Hz second Hz second Hz second Hz second Hz second
