Status LEDs
STREAM
OFF
Indicates that Monarch HD is set to Record-only
mode. In this mode, the Stream button is disabled.
Blue
(solid)
Indicates that Monarch HD is set to stream in RTSP
or RTMP mode.
Blue
(flash)
Streaming in progress. If set to RTSP mode, the
Stream LED flashes when a client is currently
connected to the Monarch HD device. If set to RTMP
mode, the Stream LED flashes when a stream is
started using the Stream button on the device or when
using the control buttons in the Command Center. If a
disconnection occurs while in Stream-only mode, the
LED will flash faster while the device attempts to
reconnect. The LED will go back to the regular
flashing speed once it automatically establishes a new
connection.
STREAM
and
RECORD
Blue
(solid)
Indicates a disconnection in Stream and Record
mode. The LED will stop flashing upon
disconnecting (The device is not trying to establish a
new connection) and will stay this way until it is
manually restarted.
RECORD
OFF
Indicates that Monarch HD is set to Stream-only
mode. In this mode, the Record button is disabled.
Red (solid)
Indicates that Monarch HD is set to record to the
selected media.
Red (flash) Recording in progress.
USB ports
1/2
OFF
USB port 1/USB port 2 is not selected as the
recording media, or Monarch HD is set to
Stream-only mode.
Red (solid)
USB port 1/USB port 2 is selected as the recording
media.
Red (flash)
Monarch HD is currently writing to the media device
connected to USB port 1/USB port 2. Do not remove
the USB device when its LED is flashing. Doing so
may result in corrupted video files.
