33
T50/T100 PTM – User Guide – Version 2 Issue 1
Maintenance – Ink-Filter Replacement
15. Make sure that the rubber seal inside the Ink-Inlet is clean and correctly seated. Make
sure that there is only one seal.
16. Put the Ink-Bottle into the Ink-Inlet and tighten it with forefinger and thumb pressure only.
17. Connect the power supply to the PTM. Wait until the READY LED on the back of the
PTM illuminates green.
Note: The READY LED will illuminate green when the PTM has reached the correct
operating temperature, which takes approximately two minutes. It will illuminate orange
while warming up.
18. Press and hold the Prime button on the back of the PTM for five seconds and then
release it. A distinct sound can be heard when the Prime sequence starts, allow the
sequence to complete.
Note: The prime function pumps ink to the nozzles and takes approximately thirty
seconds to complete.
19. Make a test print and verify that a satisfactory printout is produced. If the quality of print is
poor refer to and follow the procedure for “Purging Trapped Air” on page 29
The PTM is now ready for use.
