Repair Comet Executive Gas
7-14
Figure 7-12: Proper positioning of the feed table is important for the atwork to feed properly into the ironing
section.
3/8" (9 mm) GAP
IRONING CYLINDER
FEED TABLE
BOTTOM VIEW
11. Position the table 1/4” (6 mm) from the
ironing cylinder. Tighten the bolts to se-
cure the table in that position.
12. Repeat Steps 10 and 11 at the other end
of the unit.
13. Make sure the spacing at each end of the
unit is 1/4” (6 mm) and the bolts in the
slotted holes are securely tightened.
14. Refasten the feed ribbons. Make sure the
ribbons are below the rod, and also below
and between the feed ribbon guides. Stag-
ger the positions of the lacing clips to give
the atwork a smooth ow.
15. Adjust ribbon tension; refer to Feed Rib-
bon Tension Adjustment on page 7-5.
80” Machines
Checking Alignment and Positioning
Improper handling of the unit during shipping
can cause too much tension on the feed table,
making it bow upward excessively.
A feed table that is in poor alignment is usually
due to heavy items being set on it, or people
standing on it.
Over time, normal daily use also causes the
table to sag slightly. Any of these conditions may
cause atwork to feed improperly.
When properly aligned and positioned, the
feed table will bow slightly upward in the middle.
The leading edge should be 1/4” (6 mm) from the
ironing cylinder at either end and 3/8” (9 mm)
from the ironing cylinder in the middle (Figure
7-12).
