201
Controls in detail
Automatic climate control
1 Side air vent, left, adjustable
2 Center air vent, left, adjustable
3 Fixed air vent
4 Center air vent, right, adjustable
5 Side air vent, right, adjustable
6 Thumbwheel for right side air
vent
7 Thumbwheel for right center air
vent
8 Automatic climate control panel
9 Thumbwheel for left center air
vent
a Thumbwheel for left side air vent
Warning! G
When operating the automatic climate
control, the air that enters the passenger
compartment through the air vents in the
footwell can be very hot or very cold (de-
pending on the set temperature). This may
cause burn or frostbite on unprotected
skin in the immediate area of the air vents.
Always keep sufficient distance between
unprotected parts of the body and the
footwell air vents. If necessary, change the
air flow using the air distribution controls
to direct the air away from the footwell air
vents ( page 203).
