458
Technical data
Engine
Model Maybach
1
Engine 285
Mode of operation 4-stroke engine, gasoline injection
No. of cylinders 12
Bore 3.23 in (82.00 mm)
Stroke 3.43 in (87.00 mm)
Total piston displacement 336.4 cu in (5513 cm
3
)
Compression ratio 9:1
Output acc. to SAE J 1349 543 hp/5250 rpm
2
(405 kW/5250 rpm)
Maximum torque acc. to SAE J 1349 664 lb-ft/2300–3000 rpm
(900 Nm/2300–3000 rpm)
Maximum engine speed 5950 rpm
Firing order 1-12-5-8-3-10-6-7-2-11-4-9
Poly-V-belt 2713 mm
1 The quoted data apply only to the standard vehicle. See an authorized Maybach Studio for the corre-
sponding data of all special bodies and special equipment.
2 Premium fuel required. Performance may vary with fuel octane rating.
