At a glance
Instrument cluster
Item Page
1 Coolant temperature
gauge
154
2 Fuel gauge with fuel
reserve warning lamp
389
3 L Left turn signal indi-
cator lamp
71
4 Speedometer 156
5 v Antilock Brake Sys-
tem (ABS)/Electronic
Stability Program
(ESP) warning lamp
384
6 l Distance warning
lamp
1
1 Vehicles without Distronic**: Warning lamp
without function. It illuminates when the igni-
tion is on. It should go out when the engine is
running.
385
7 K Right turn signal in-
dicator lamp
71
8 Tachometer 154
Item Page
9 - Antilock Brake Sys-
tem (ABS) indicator
lamp
385
a A High beam head-
lamp indicator lamp
147
b J Reset button
c < Seat belt telltale 386
d Digital clock
(see COMAND and Rear-
Cabin Audiovisual System
operating instructions)
e Gear selector lever position
and program mode
185
f Main odometer 157
g Trip odometer 157
h Multifunction display 157
j Outside temperature indi-
cator
155
Item Page
k H Tire pressure warn-
ing lamp
389
l Knob for instrument cluster
illumination
153
m ? Engine malfunction
indicator lamp, USA
only
389
± Engine malfunction
indicator lamp, Can-
ada only
389
n ; Brake warning lamp,
USA only
388
3 Brake warning lamp,
Canada only
388
o 1 Supplemental
Restraint System
(SRS) indicator lamp
387
