91
Safety and Security
Occupant safety
Installing infant and child restraint sys-
tems
This vehicle is equipped with tether an-
chorages for a top tether strap at each of
the rear seating positions.
1 Cover of top anchorage ring
Bring the rear seat backrest to a fully
upright position.
Open cover 1 to access anchorage
ring.
Guide tether strap between head re-
straints and top of seat back.
Head restraint must be positioned such
that the top tether strap can pass freely
between the head restraint and top of
seat back.
Make sure the tether strap is not
twisted.
2 Hook
3 Anchorage ring
Securely fasten hook 2, which is part
of the tether strap, to anchorage
ring 3.
Once the top tether anchorage hook is
attached, the child restraint itself can be
secured. Tighten the top tether strap ac-
cording to the child restraint manufac-
turer's instructions.
Close cover after removing the tether
strap.
i
For safety, please make sure the hook
has attached to the ring beyond the
safety catch, as illustrated.
Warning! G
Never adjust the rear seat position after in-
stalling the child restraint. Adjusting the
rear seat position after installing the child
restraint could damage the child restraint
and/or introduce undesirable slack into the
webbing and loosen or misposition the
child restraint, lessening the effectiveness
of the child restraint and thus increasing
the chance or severity of injury in an acci-
dent.
