11.Turn the hexagonal wrench (Small)
and gear (tool kit) counterclockwise
and engage the hook with the
vehicle body side.
NOTE
The top lock lever completely
engages with the vehicle body
(locked condition) at the position
where the teeth of the gear (tool
kit) contact the bracket.
1. Bracket
2. Gear (tool kit)
12.Lift the rear end of the headliner
with it hinged on the opening of
the headliner.
13.Install the headliner to the front
roof using the fasteners at two
locations.
NOTE
The fasteners in the five locations at
the front of the headliner are not
fastened. Do not lose the fasteners
because they are needed for the
required servicing at an Authorized
Mazda Dealer.
What to Do in Case of Emergency
When the Roof Cannot be Closed
8-43
